24.6"x24.6"(625*625mm) Square Deck Hatch - Anodized Aluminum Boat Hatch for Boat/Yacht/RV

24.6"x24.6"(625*625mm) Square Deck Hatch - Anodized Aluminum Boat Hatch for Boat/Yacht/RV

$490.00 USD
$558.00 USD $490.00 USD
促销 售罄
Size

  • Heavy-duty Anodized Aluminum Square Hatch Frame for Corrosion Resistance;

  • Come with 0.24" (6mm) thick of Smoke-Grey Tempered Glass Top, 316 stainless steel support, and durable hinges;

  • Provide protection against the elements. Good for boat, yacht, ship, and RV;

  • Please check the Dimension Table for the overall size and cutout size of each model.

  • Dimensions of this hatch model:

           Overall Size is 24.6"x24.6"(625mmx625mm),
            Cut-out Size is 22"x22" (560mmx560mm),


             Corner Radius: R1.8 inch (R45mm)

  • Dimensions of Each Square Hatch Models:

Model No.

(Inch)

A:  Overall Size (Inch)

B: Cut-out Size (Inch)

C. See-through Size (Inch)

16.7 x 16.7

16.7 x 16.7

14.2 x 14.2

12 x 12

18.7 x 18.7

18.7 x 18.7

16.1 x 16.1

15 x 15

20.7 x 20.7

20.7 x20.7

18.1 x 18.1

16.9 x 16.9

22.6 x 22.6

22.6 x 22.6

20 x 20

18.9 x 18.9

24.6 x 24.6

24.6 x 24.6

22 x 22

20.9 x 20.9

26.6 x 26.6

26.6 x2 6.6

24 x 24

22.8 x 22.8

Corner Radius: R1.8 inch (R45mm)

NOTE:

  • Important - Please measure carefully before placing your order. The model number is the Overall size of the hatch, but not the Cutout size.

  • Please refer to the above Dimension Table for the Cut-out Size.

  • The latch works from inside only ( Leak-free design on handles)
